Product Overview
The Automatic Carton Stitcher Machine is a post-processing equipment used for stitching corrugated cartons with metal wire. It integrates automatic paper feeding, folding, carton correction, stitching, counting and stacking output functions in one machine.
The machine is designed for corrugated carton manufacturers requiring automatic stitching production. It is suitable for 3-ply and 5-ply corrugated cartons., with 7-ply carton processing available according to machine configuration and customer requirements.
Key Features
- The whole machine is controlled by PLC and touch screen operation. Production parameters can be entered through the interface for convenient adjustment.
- Servo motor control is applied to the stitching head, ensuring stable and accurate nail positioning.
- The machine supports single stitching, double stitching and reinforced stitching according to carton requirements.
- The paper feeding section uses front belt feeding with side alignment device to reduce carton feeding deviation.
- The folding section uses belt conveying and vacuum belt conveying, helping reduce slipping and skewing problems during operation.
- The correction section reshapes folded cartons before stitching to reduce carton misalignment and improve stitching accuracy.
- The machine can store production orders, allowing commonly used carton sizes to be recalled for repeated production.
- The machine supports automatic counting and stacking output after stitching.
- Optional bundling unit is available according to production requirements.
Technical Parameters
| Specifications and models | 2600 model | 2800 model | 3000 model |
| Mechanical size (M) | 3*12 | 3.2*12 | 3.4*12 |
| Total power (approx. Kw) | 12 | 12 | 12 |
| Maximum board (mm) | 1200*2200 | 1200*2400 | 1200*2600 |
| Minimum board (mm） | 350*800 | 350*800 | 350*800 |
| Design speed | 60pcs/min | ||
| Economic speed | 50pcs/min | ||
| Nail spacing range nail | 50-90mm | ||
Technical parameters may vary according to machine configuration and carton size.
Main Configuration
| Equipment | Function |
|---|---|
| Paper Feeding Unit | Automatic cardboard feeding and alignment |
| Folding Unit | Carton folding and conveying |
| Correction Unit | Carton shaping before stitching |
| Stitching Unit | Metal wire stitching |
| Counting & Stacking Unit | Automatic counting and output |
Suitable Materials
- 3-ply corrugated cartons
- 5-ply corrugated cartons
- 7-ply corrugated cartons (optional)
Applications
Suitable for:
- Corrugated Box Manufacturers
- Carton Factories
- Packaging Companies
Applicable Products:
- Regular corrugated cartons
- Heavy-duty corrugated cartons
- Shipping cartons
- Industrial packaging cartons
Working Process
Slotted Carton Blank Feeding
↓
Automatic Folding
↓
Alignment Correction
↓
Wire Stitching
↓
Automatic Counting
↓
Stacking Output
Why Choose This Machine
- Automatic carton forming and stitching
- Servo-controlled stitching accuracy
- Reduced labor costs
- Stable production for continuous operation
- Order memory for quick job changeover
Recommended Industries
Suitable for:
- Corrugated Packaging Plants
- Carton Manufacturing Companies
- Industrial Packaging Producers
- Logistics Packaging Suppliers
FAQ
1. What type of cartons can this automatic carton stitcher machine process?
It is mainly used for 3 ply and 5 ply corrugated cartons. Processing of 7 ply cartons should be confirmed according to machine configuration.
2. What is the difference between carton stitching and carton gluing?
Carton stitching uses metal wire to join carton flaps, while carton gluing uses adhesive bonding. Stitching is commonly used for cartons requiring additional mechanical strength.
3. Can this machine perform different stitching methods?
Yes. According to carton requirements, the machine can perform single stitching, double stitching and reinforced stitching.
4. How many carton orders can the machine store?
The control system can store up to 800 production orders according to the original technical specification.
5. Does the machine automatically count and stack cartons?
Yes. After stitching, the machine can automatically count and stack cartons for output.
6. Can the machine process different carton sizes?
Yes. The machine can adjust according to carton specifications. The exact adjustment range depends on the machine model and configuration.
