Product Overview
The Automatic Folder Gluer Stitcher Machine is an integrated corrugated box converting machine that combines paper feeding, folding, gluing, stitching, counting and stacking processes in one production system. It is designed for automatic forming of corrugated cartons requiring adhesive bonding and stitching reinforcement.
The machine uses PLC control, touch screen operation and synchronized drive systems to achieve stable carton processing. It is suitable for carton manufacturers producing various corrugated boxes that require both gluing and stitching functions.
Key Features
Integrated Folding, Gluing and Stitching Process
The machine integrates automatic paper feeding, folding, gluing, stitching, counting and stacking functions, reducing manual operation during carton forming.
PLC Control and Order Management
- PLC control system with touch screen operation.
- Supports production parameter adjustment and order storage.
- One-button order change function helps simplify repeated production operations.
Paper Feeding and Gluing Unit
- High-strength belt suction feeding system improves feeding stability and adapts to curved corrugated cardboard.
- Independent paper feeding control system with electromagnetic clutch and brake structure.
- Pre-pressing wheels help improve carton forming quality.
- Stainless steel glue coating wheels provide uniform glue application and easy cleaning.
Folding Unit
- High-strength conveying belts ensure stable cardboard transportation.
- Equipped with carton creasing correction structure to improve folding accuracy.
- Linear guide adjustment structure provides convenient operation and stable positioning.
- Suitable for processing corrugated cardboard with different thicknesses.
Stitching Unit
- The stitching head can be adjusted according to carton production requirements.
- Supports switching between gluing mode and stitching mode.
- Stitching head components are precision processed to maintain stable stitching performance.
- Electric adjustment system allows convenient size adjustment according to carton dimensions.
- Dual servo drive system provides accurate mechanical transmission.
Counting and Stacking Unit
- Automatic carton counting and stacking system.
- PLC and touch screen control provide accurate operation.
- Equipped with carton alignment correction function to reduce forming deviation.
- Slow-stop conveyor section provides pressing time after gluing to improve bonding stability.
Technical Parameters
| 2800 type | 3000 type | |
| Max cardboard size(mm） | 2400×1200mm | 2600×1200mm |
| Min cardboard size (mm) | 420×160mm（folding gluing）680×200mm（stitching） | 420×160mm（folding gluing）680×200mm（stitching） |
| Outer machine size (mm) | 15000×3500×2000mm | 15000×3700×2000mm |
| Total motor power（kw） | 25 | |
| Supply voltage（V） | 380 | |
| Machine working speed | 150 m/min 80 pcs/min | |
| Total weight | /6 Ton | |
Technical parameters can be customized according to customer requirements.
Suitable Materials
The machine is suitable for:
- 3/5/7 ply Corrugated cardboard
Applications
Suitable for:
- Corrugated carton manufacturers
- Packaging companies
- Carton converting factories
Applicable Products:
- Shipping cartons
- Industrial corrugated boxes
- Packaging cartons requiring gluing and stitching reinforcement
Working Process
Corrugated Cardboard Feeding
↓
Glue Application
↓
Folding Forming
↓
Stitching (According to Box Requirement)
↓
Counting
↓
Stacking and Output
Why Choose This Machine
- Integrated folding, gluing and stitching functions
- Automatic feeding and carton forming process
- PLC control for convenient operation
- Adjustable structure for different carton sizes
- Suitable for carton production requiring adhesive bonding and stitching
Recommended Industries
Suitable for:
- Corrugated Packaging Plants
- Carton Manufacturing Companies
- Industrial Packaging Manufacturers
- E-commerce Packaging Suppliers
FAQ
1. What is an automatic folder gluer stitcher machine used for?
It is used for automatic forming of corrugated cartons by combining folding, gluing and stitching processes in one machine.
2. What is the difference between a folder gluer and a folder gluer stitcher machine?
A folder gluer only uses adhesive bonding to form cartons, while a folder gluer stitcher machine adds stitching capability for cartons requiring additional reinforcement.
3. Can this machine process different carton sizes?
Yes. The machine structure allows adjustment according to different carton dimensions. Production parameters can be adjusted through the control system.
4. What type of cartons usually require stitching?
Large-size or heavy-duty corrugated cartons often use stitching together with gluing when stronger carton sealing is required.
5. Does the machine support both gluing and stitching production modes?
Yes. The stitching unit can be adjusted according to production requirements, allowing carton production with gluing or stitching functions.
6. How does the machine improve carton forming consistency?
The machine uses automatic feeding, folding correction, controlled gluing and automatic stacking systems to maintain stable carton forming quality.
7. What maintenance is required for the folder gluer stitcher machine?
Regular cleaning of glue components, checking belts, lubrication of moving parts and inspection of electrical and pneumatic components are recommended.
